Technical Specifications
| Parameter | Value |
|---|---|
| Model |
SLAMTEC Mapper M2M3 |
| Distance Range | 40m |
| Sample Rate |
10kHz |
| MaximumArea |
300m*300m
|
| Mapping resolution | 0.05m |
| Maximum moving speed | 2m/s |
| Maximum rotation speed | TBD |
| Accuracy | <0.02m |
| Graph Optimizing Working Time | About1hr |
| Maximum Inclination Angle |
±3° |
| Frequency of data refresh | 10Hz |
| Laser wavelength | 895-915nm |
| Laser power | 25W |
| Pulse length | 5ns |
| Laser Safety Class |
IEC-60825 Class 1 |
| Power Voltage |
4.95—5.3V |
| Power Voltage Ripple |
50mV |
| System Start Current |
1200mA |
| Power Current | 650mA |
|
Weight
|
163g
|
|
Working Temperature Range
|
-5—45ºC
|
