BLINX OpenH5 Robotic Arm
Regular price
$36,000.00
Unit price
BLINX OpenH5 Robotic Arm - OpenH5 is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Arm DOF | 7 |
| Arm Load | 3kg |
| Arm Length | 750mm |
| Working Radius | 450mm |
| Repeat Positioning Accuracy | ±0.1mm |
| Weight | 12kg |
| Wrist Expansion | Two-finger gripper, five-finger dexterous hand, etc. |
| Supply Voltage & Current | 24V / 25A DC |
| Rated Power | 1000W Max |
| Operating Environment | -10°C ~ 60°C |
| Communication Method | WiFi / RJ45 |
| Control Method | One controller for two arms |
| Base Dimensions | 110 × 110mm |
| Joint Motion Range & Max Speed | |
| J1 | ±179°, 180°/s |
| J2 | ±96°, 180°/s |
| J3 | ±179°, 225°/s |
| J4 | ±123°, 225°/s |
| J5 | ±179°, 225°/s |
| J6 | ±91°, 225°/s |
| J7 | ±179°, 225°/s |
