DexRobot

DexRobot DexHand021 Pro

$57,000.00
Version
Left/Right

Delivery and Shipping
  • We automatically select the most cost-effective carrier from China for each destination country
  • Shipping rates are dynamically calculated based on real-time quotes
  • Final rates may vary due to promotional offers or carrier adjustments

Product Information

Application Scenarios

Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots

Technical Specifications

Parameter Value
Model DexHand021 Pro
Number of Fingers 5
Self-weight 2kg
Degree of Freedom 22 DOF (16 main + 4 driven + 2 wrist)
Drive Mode Coreless Motor + Linear Push Rod
Transmission Mode Tendon Rope Transmission, Double Rope Drive
Load 5kg
Sensor Position/Fingertip/Finger Pad/Palm Sensing
Operating Voltage DC 24V-48V
Static Current 0.2A
Maximum Current /
Communication Method CANFD/Ethercat
Control Mode Position control / Trajectory control / Force control
Operating System FreeRTOS/SDK supports ROS
Tactile Sensor Parameters Normal force range: 20N; proximity sense ≥ 1cm
Minimum opening and closing time 0.6s
Fan heat dissipation capacity /
