DOBOT | SKU:
DOBOT MG400 Collaborative Robot
Regular price
$3,700.00
Unit price
DOBOT MG400 Collaborative Robot - MG400 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
DOBOT MG400 Collaborative Robot
Regular price
$3,700.00
Unit price
DOBOT MG400 Collaborative Robot - MG400 is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | |
|---|---|
| Model | DT-MG400-4R075-01 |
| Controled Axes | 4 |
| Rated Load | 500g (Max. 750g) |
| Max. Reach | 440mm |
| Repeatibility | ±0.05mm |
| Joint Range | J1: ±160° J2: -25°-85° J3: -25°-105° J4: -360°-360° |
| Joint Speed | J1: 300°/s J2: 300°/s J3: 300°/s J4: 300°/s |
| Power Input | 100~240 V AC, 50/60 Hz |
| Rated Voltage | DC 48 V |
| Rated Power |
J1:75W |
| Communication | TCP/IP, Modbus TCP |
| Installation | Desktop |
| Weight | 8kg |
| Base Dimension | 190 mm × 190 mm |
| Working environment humidity | 5%-85% relative humidity |
| Storage humidity | ≤95％ relative humidity |
| Software | DobotStudio 2020, SCStudio |
