Daimon Robotics | SKU:
Daimon Robotics DM-Tac G Tactile Gripper
Regular price
$6,200.00
Unit price
Daimon Robotics DM-Tac G Tactile Gripper - DM-Tac G Tactile Gripper is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
Daimon Robotics DM-Tac G Tactile Gripper
Regular price
$6,200.00
Unit price
Daimon Robotics DM-Tac G Tactile Gripper - DM-Tac G Tactile Gripper is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Size (mm) | 184.6 × 162.3 × 67 |
| Weight | 1kg |
| Unilateral clamping force | 45 ~ 60N |
| Total Itinerary (mm) | 95 |
| Opening/Closing time | 0.9 s/0.9 s |
| Position repeatability (mm) | ± 0.03 |
| Operating noise | < 60 dB |
| Transmission method | Screw nut + connecting rod mechanism |
| Operating voltage | 24 V DC ±10% |
| Rated current | 0.8A |
| Peak current | 1.5A |
| Recommended usage environment | 0~40°C, below 85% RH |
| Communication Protocol | Standard Configuration: Modbus RTU (RS485), Digital I/O Optional Features: TCP/IP, USB 2.0, CAN 2.0A, PROFINET, EtherCAT |
