CASBOT | SKU:
CASBOT 02 Robot
Regular price
$63,500.00
Unit price
Unavailable
CASBOT 02 Robot - CASBOT 02 Standard Edition is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
CASBOT 02 Robot
Regular priceFrom
$63,500.00
Unit price
Unavailable
CASBOT 02 Robot - CASBOT 02 Standard Edition is backordered and will ship as soon as it is back in stock.
Product Information
Technical Specifications
| Parameter | Standard Edition | EDU Edition |
|---|---|---|
| Height/Width/Depth (Standing) | 1630*510*280mm |
1630*510*280mm |
| Total Weight (with Battery) |
50kg |
52kg |
| Total DOF (excluding Dexterous Hands) |
25DoF |
25DoF |
| Head DOF |
2DoF |
2DoF |
| Single Arm DOF |
5DoF |
5DoF |
| Waist DOF |
1DoF |
1DoF |
| Single Leg DOF |
6DoF |
6DoF |
| Dexterous Hand |
11DoF (6 Active) | 11DoF (6 Active) |
| Single Arm Payload |
1.5kg |
1.5kg |
| Maximum Joint Torque |
150N.m |
150N.m |
| Walking Speed | 1m/s |
1m/s |
| Battery Specification | 48V10Ah |
48V10Ah |
| Overall Endurance | Approx. 1.5h | Approx. 1.5h |
| Computing Power | 275TOPS |
275TOPS |
| Robot Control Unit (RCU) | OrinAGX |
OrinAGX |
| Human-Robot Interaction Unit (HRU) | RK3588 |
RK3588 |
| Communication | WiFi 6 / 4G / Bluetooth 5.2 | WiFi 6 / 4G / Bluetooth 5.2 |
| Cooling System | Air Cooling System | Air Cooling System |
| Operating Environment | Temperature: 5-40°C Humidity: 25%-85% (Non-Condensing) |
Temperature: 5-40°C Humidity: 25%-85% (Non-Condensing) |
| Microphone Array & Speaker | 1 | 1 |
| LiDAR | / | 1 |
| IMU Sensor | 1 | 1 |
| RGBD Camera | 1 | 3 |
| Stereo Camera | 1 | 1 |
| Fisheye Camera | 2 | 2 |
| Navigation | / | Supported |
| Wireless Charging | / | Supported |
| Teleoperation Kit (incl. VR Equipment) | Optional | Optional |
| Control Method | Handheld Controller / Teleoperation / App | Handheld Controller / Teleoperation / App |
| Battery | Li-ion NMC Battery (1 Included as Standard, Additional Units Available Separately) | Li-ion NMC Battery (1 Included as Standard, Additional Units Available Separately) |
| Charger | 1 | 1 |
| Remote Controller | Handheld Controller 1 (Tablet Optional) | Handheld Controller 1 (Tablet Optional) |
| Wireless Emergency Stop | 1 | 1 |
| Hoisting Rope | 1 | 1 |
| Lifting Ring | 2 | 2 |
| Electronic Product Manual | 1 | 1 |
| Packing List | 1 | 1 |
| Smart OTA Updates | Supported | Supported |
| Secondary Development | / | Supported |
| Appearance Customization | / | Supported |
| Standard Features | Preloaded Basic Motion Library, Operable via Handheld Controller | General-Purpose Secondary Development and Educational Kit |
