SLAMTEC | SKU:
SLAMTEC Aurora LiDAR
Regular price
$1,150.00
Unit price
SLAMTEC Aurora LiDAR - Aurora is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
SLAMTEC Aurora LiDAR
Regular price
$1,150.00
Unit price
SLAMTEC Aurora LiDAR - Aurora is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
|
Power input
|
DC12V-2A (DC5.5x2.1mm)
|
|
Power
|
10W (typical)
|
|
Data interface
|
1 x USB-C (No power delivery)
1 x Ethernet (RJ45)
|
|
Wireless connection
|
WIFI
|
|
Weight
|
505g
|
|
Working temperature
|
0℃~40℃
|
|
2D map resolution
|
2Cm/5cm/10cm adjustable
|
|
Maximum Mapping area
|
>1,000,000 ㎡
|
|
Relocation
|
Support global relocation
|
|
Map continuation
|
Support
|
|
Map loading and saving
|
Support
|
|
Map localization mode
|
Laser + vision+ inertial navigation multi-source
fusion
|
|
Multi-sensor synchronization mechanism
|
Hardware time synchronization
|
|
LIDAR distance measurement
|
maximum range 40m@70% reflectivity
|
|
Camera specifications
|
Binocular fish eye global camera, supports HDR,
FOV 180 °, 6cm base line
|
|
Camera frame rate
|
Typical 10Hz, 15/30Hz can be customized
|
|
Maximum tilt angle
|
No requirements, (to ensure the 2D drawing
effect, it is recommended that the tilt angle does
not exceed 30 °)
|
