WitMotion | SKU:
WitMotion WTVB02 Sensor
Regular price
$100.00
Unit price
WitMotion WTVB02 Sensor - WTVB02-485 (Magnetic Mount) is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
WitMotion WTVB02 Sensor
Regular priceFrom
$95.00
Unit price
WitMotion WTVB02 Sensor - WTVB02-485 (Magnetic Mount) is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Operating Temperature | -40°C ~ +85°C |
| Storage Temperature | -40°C ~ +85°C |
| Shock Resistance | 20000g |
| Protection Class | IP68 |
| Supply Voltage | 9V ~ 36V (default 12V) |
| Operating Current (Active, 12V) | 10mA |
| Power Consumption | 120mW |
| Communication Interface | RS485, 4800~230400bps (default 9600) |
| Output Content | On‑chip time, 3‑axis Accel, 3‑axis Vibration Velocity, 3‑axis Vibration Displacement, 3‑axis Vibration Frequency, Temperature |
| Measurement Range | Velocity: 0~600mm/s, Displacement: 0~60000µm, Frequency: 5~2000Hz |
| Accuracy | < F.S ±4% |
