Seyond | SKU:
Seyond Robin W LiDAR
Regular price
$2,900.00
Unit price
Seyond Robin W LiDAR - Robin W is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
Seyond Robin W LiDAR
Regular price
$2,900.00
Unit price
Seyond Robin W LiDAR - Robin W is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Detection Capability | |
| Laser Wavelength | 905nm |
| Detection Range | 0.1 ~ 150m |
| Detection Distance | 70m, POD>90% (10% reflectivity @10Hz) |
| Range Precision | Up to 1cm @ 1σ |
| Range Accuracy | ±2cm |
| Field of View (H×V) | 120° × 70° |
| Angular Resolution (H×V) | 0.15° × 0.36° |
| Frame Rate | 10 ~ 20 FPS |
| Operating Conditions | |
| Rated Voltage | 12VDC (Operating: 9~28VDC) |
| Operating Current | 0.6A @12V (typical, 20°C) |
| Rated Power | 7.2W (typical, 20°C) |
| Operating Temperature | -40°C ~ +85°C |
| Ingress Protection | IP67 (body), IP69K (window) |
| Certification | IEC60825-1:2014 Class 1 |
| Mechanical Structure | |
| Dimensions (H×W×D) | 85mm × 104.8mm × 106.7mm |
| Weight | 800g |
| Connector | Proprietary pluggable connector (Power + Automotive Ethernet) |
| Data Transmission & Control | |
| Data Interface | 1000Base-T1 Automotive Ethernet (UDP, TCP) |
| Data Output | Radial distance, horizontal & vertical angles, reflectivity, timestamp |
| Point Frequency | 1,280,000 pts/s (single return @10Hz) |
| Point Cloud Data Rate | 60Mbps, single return |
| Time Synchronization | gPTP / PTP / NTP |
| Return Mode | Single return / Dual return |
