WUJI

WUJI HAND 2

$19,500.00
Version
Left/Right

Delivery and Shipping
  • We automatically select the most cost-effective carrier from China for each destination country
  • Shipping rates are dynamically calculated based on real-time quotes
  • Final rates may vary due to promotional offers or carrier adjustments

Product Information



Application Scenarios

Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots

Technical Specifications

Parameter Value
STRUCTURE Active DoF: 20 DoF
Finger Configuration: Full opposition, lateral movement
Kinematics: Direct-drive rotary, back-drivable
Dimensions: ≈ 185 × 80 × 40 mm
Min. Grasping Diameter: Zero grasping radius
SENSING Fingertip Force Sensing: Multi-axis force/torque fingertip sensing
CONTROL Frequency: 1000 Hz × 20 axes
Mode: MIT force-position hybrid
COMM Protocol: EtherNet (1000BASE-T)
PAYLOAD Fingertip Peak Force: ≥ 15 N
DYNAMICS Open / Close Speed: ≥ 4 cycles / s
PRECISION Joint Backlash: < 1°
ELECTRICAL Operating Voltage: 16–58 V DC
WUJI HAND 2 Left.stp

WUJI HAND 2 Right.stp
