Cyborg | SKU:
Cyborg-H02 Robotic Hand
Regular price
$5,500.00
Unit price
Cyborg-H02 Robotic Hand - Cyborg-H02 / Left is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
Cyborg-H02 Robotic Hand
Regular price
$5,500.00
Unit price
Cyborg-H02 Robotic Hand - Cyborg-H02 / Left is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Drive Method | Tendon-Driven |
| Wrist Width | 40mm |
| Hand Width | 114mm |
| Max Hand Length | 248.5mm |
| Longest Finger Length | 104mm |
| Palm Thickness | 52mm |
| Rated Load per Finger | 5kg |
| Rated Load for Whole Hand | 15kg |
| Thumb Fingertip Output Force | 15N |
| Other Four Fingers Fingertip Output Force | 15N |
| Number of Joints | 16 |
| Number of Motors | 6 |
| Fingertip Tactile Sensor Range | 0-20N |
| Static Current | 170mA |
| Communication Interface | RS485 / CAN |
| Operating Voltage | 12V |
| Four-Finger Bending Angle | ≤90° |
| Thumb Bending Angle | ≤74.2° |
| Thumb Lateral Rotation Range | ≤130° |
| Thumb Lateral Swing Speed | 216°/s |
| Four-Finger Open/Close Time | 1.16s |
| Weight | 750g |
