HITBOT Z-Arm S1400 Robotic Arm
Regular price
$13,500.00
Unit price
HITBOT Z-Arm S1400 Robotic Arm - Z-Arm S1400 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
HITBOT Z-Arm S1400 Robotic Arm
Regular price
$13,500.00
Unit price
HITBOT Z-Arm S1400 Robotic Arm - Z-Arm S1400 is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 40kg |
| Efficient Load | 10kg |
| Work Radius | 1400mm |
| Moving range of joint, Software Limit | 1 Axis: ±175°; 2 Axis: +85°, -265°; 3 Axis: ±160°; 4 Axis: +85°, -265°; 5 Axis: ±175°; 6 Axis: ±175° |
| The Max Speed of Joint | 180°/s |
| Repeatability | ±0.05mm |
| Installation Area | Ø190mm |
| Size of Control Box | 342*260*90mm (No including protuberance) |
| Degree of Freedom | 6 |
| Terminal I/O Port | Digital Input: 2, Digital Output: 2; Simulation input: 1, Simulation Output: 1 |
| Control Box I/O Port | Digital Input: 16, Digital Output: 16; Simulation input: 2, Simulation Output: 2 |
| I/O Power Supply | 24V/1.5A |
| Communication | Ethernet, TCP/IP, 485 Communication |
| Noise | <65dB |
| Protection Grade | IP54 |
| Collaborative to Operate | It has the function of collision test, permit to customize collision level |
| Input | 220V/50HZ |
| Working Environment | Away from vibration and vibration should be below 0.5G.; Away from corrosion air, fluid and explosive air.; Away from dust, smog and water.; Away from product to work under the condition of unstable current. |
| Humidity | 20-80RH (No Condensation) |
| Temperature | 0-45℃ |
