HITBOT

HITBOT Z-Arm 4160 Robotic Arm

$8,700.00
Version

Delivery and Shipping
  • We automatically select the most cost-effective carrier from China for each destination country
  • Shipping rates are dynamically calculated based on real-time quotes
  • Final rates may vary due to promotional offers or carrier adjustments

Product Information

Application Scenarios

Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots

Technical Specifications

Parameter Value
Arm Span of 1-Axis 325mm
Rotation angle of 1-axis ±90°
Arm Span of 2-Axis 275mm
Rotation angle of 2-axis ±164°
Stroke of Z-axis 410mm (customized height)
Rotation range of R-axis ±1080° no mechanical limit / ±170° with mechanical limit
Linear Speed 1500mm/s (load 3kg)
Repeatability ±0.05mm
Standard Load 3kg
The Max Load 3.5kg
Degree of Freedom 4
Input 220V/110V, 50-60Hz
Communication Ethernet
Customized Height of Z-Axis 0.1m-1m
The reserved interface for electric equipment Standard: 2pcs 4*23awg (no shielding layer) cable
Option: 2pcs φ air tube
Optional Accessories Z-EFG-8S/Z-EFG-12/Z-EFG-20/Z-EFG-20S/Z-EFG-20F/Z-EFG-20C/
Z-EFG-30/Z-EFG-50/Z-EFG-100, the fifth axis, 3D print
Work Environment Temperature: 0-45°, relative humidity: 20-80RH (no frost)
I/O Digital Input (Isolation) 9+3+small arm extension (8-in, 8-out; 485 or pulse)
I/O Digital Output (Isolation) 9+3+small arm extension (8-in, 8-out; 485 or pulse)
I/O Simulation Input (4-20mA) /
I/O Simulation Output (4-20mA) /
Product Height 830mm
Product Weight 410mm stroke, product weight: 28.5kg
Size of foundation 250mm250mm15mm
Interval of fixed hole in foundation 200mm*200mm with 4pcs M8*20 screws
Collision Test /
Drag Teaching /
Instant Stop for Emergency √
