OAKChina | SKU:
OAKChina OAK-D-Pro-W Camera
Regular price
$1,160.00
Unit price
OAKChina OAK-D-Pro-W Camera - OAK-D-Pro-W / IMX378 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
OAKChina OAK-D-Pro-W Camera
Regular priceFrom
$1,160.00
Unit price
OAKChina OAK-D-Pro-W Camera - OAK-D-Pro-W / IMX378 is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | RGB Camera | RGB Camera (Global Shutter) | Stereo Camera |
|---|---|---|---|
| Image Sensor | IMX378 | OV9782 | OV9282 |
| DFOV / HFOV / VFOV | 120° D / 95° H / 93° V | 150° D / 127° H / 79.5° V | 150° D / 127° H / 79.5° V |
| Resolution | 12MP (4056 × 3040) | 1MP (1280 × 800) | 1MP (1280 × 800) |
| Maximum Frame Rate | 60 FPS | 143 FPS | 255 FPS |
| Effective Focal Length (EFL) | 2.75 mm | 1.69 mm | 1.69 mm |
| Aperture (F.NO) | 1.8 ±5% | 2.0 ±5% | 2.0 ±5% |
| Spectral Range | Visible Light | Visible Light | Visible Light + 940nm |
| Focus Range | FF: 60cm - ∞ | FF: 18cm - ∞ | FF: 18cm - ∞ |
| Lens Size (Optical Format) | 1/2.3" | 1/4" | 1/4" |
| Pixel Size | 1.55 μm × 1.55 μm | 3 μm × 3 μm | 3 μm × 3 μm |
| Shutter Type | Rolling Shutter | Global Shutter | Global Shutter |
| Emitter | |||
| Emitter Model | Belago1.1 Dot-Pattern | ||
| Dot Count | 4700 | ||
| HFOV 50% | 78° ±7% | ||
| VFOV 50% | 61° ±7% | ||
| VCSEL Wavelength | 940nm | ||
