SENSING | SKU:
SENSING SG12-IMX577C-MIPI Camera
Regular price
$229.00
Unit price
SENSING SG12-IMX577C-MIPI Camera - SG12-IMX577C-MIPI-H60K is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
SENSING SG12-IMX577C-MIPI Camera
Regular price
$229.00
Unit price
SENSING SG12-IMX577C-MIPI Camera - SG12-IMX577C-MIPI-H60K is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Sensor | Sony 12MP IMX577 RGGB |
| ISP | / |
| Chip size | 7.564 mm (H) × 5.476 mm (V) |
| Image Size | 1/2.3 inch CMOS |
| Output Pixels | 4056 (H) × 3040(V) |
| Frame rate | full resolution raw10 @60fps full resolution raw12 @40fps up to 240fps(raw10,1080P) |
| Pixel Size | 1.55um*1.55um |
| HDR Support | Yes |
| Output data | MIPI/RAW@10bit/12bit |
| Power Supply | 3.3V |
| Current | <300mA@3.3VDC |
| Camera interface | FPC |
| Connector | FH67-30S-0.5SV |
| Operating temp. | -20 to +75 |
| Performance temp. | -20 to +60 |
| Dimensions | W: 20mm, L:35mm, H:25mm |
| Weight | <50g |
SENSING-SG12-IMX577C-MIPI-Drawing.pdf
