EYOU PP08 Motor
Regular price
$260.00
Unit price
EYOU PP08 Motor - PP08-36 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
EYOU PP08 Motor
Regular priceFrom
$260.00
Unit price
EYOU PP08 Motor - PP08-36 is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value | Value |
|---|---|---|
| Model | PP08-36 | PP08D-36 |
| Motor Type | Brushless Torque Motor | Brushless Torque Motor |
| Gearbox Type | Planetary Gearbox | Planetary Gearbox |
| Diameter | 40mm | 40mm |
| Length | 52mm | 48mm |
| Weight | 190g | 199g |
| Reduction Ratio | 36:1 | 36:1 |
| Backlash | 12arcmin | 12arcmin |
| Noise | ＜70db | ＜70db |
| Temperature Range | -20~80℃ | -20~80℃ |
| Operating Voltage | 24v | 24v |
| Maximum Power | 36w | 36w |
| Rated Speed | 50rpm | 50rpm |
| Rated Torque | 1N.M | 1N.M |
| Peak Torque | 2.2N.M | 2.2N.M |
| Torque Constant | 1.1N.M/A | 1.1N.M/A |
| Axial Load Capacity | 1284N | 1284N |
| Radial Load Capacity | 2520N | 2520N |
PP08-INSTALLATION_DRAWING.pdf
PP08D-INSTALLATION_DRAWING.pdf
