CubeMars | SKU:
CubeMars GL60 II Motor
Regular price
$166.99
Unit price
/
Unavailable
CubeMars GL60 II Motor - GL60 II KV28 Motor is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
CubeMars GL60 II Motor
Regular price
$166.99
Unit price
/
Unavailable
Product Information
Technical Specifications
| Parameter | Value | Value |
|---|---|---|
| Working Voltage | 16V | 24V |
| Rated Current | 1.56A | 1.54A |
| Rated Speed | 153rpm | 319rpm |
| Rated Torque | 0.6N.M | 0.6N.m |
| Line Inductance | 6mH | 6mH |
| Peak Current | 2.75A | 4.09A |
| Package Dimensions |
160*122*42mm |
160*122*42mm |
| Peak Torque |
1N.m |
1.5N.m |
| Weight | 276g | 276g |
| Winding Resistance |
5.8Ω |
5.8Ω |
| Copper Wire |
Level E 150℃ |
Level E 150℃ |
| Motor Dimensions |
φ70.5*33.6mm |
φ70.5*33.6mm |
| Wiring Method |
/ |
/ |
| Stator Technology |
Rust-proof，180℃ coating |
Rust-proof，180℃ coating |
| Enamelled Wires Temperature Resistance Grade |
Level H 180℃ |
Level H 180℃ |
| Configuration |
24N28P |
24N28P |
| Coil Withstand Voltage |
500V 5mA/2s |
500V 5mA/2s |
| Bore Size |
φ20mm |
φ20mm |
| Rotor Inertia |
401.086g.cm² |
401.086g.cm² |
| Torque Constant |
0.34Nm/A |
0.34Nm/A |
| Waterproof and dustproof class |
/ |
/ |
| Bearings |
Imported 6705 ZZ |
Imported 6705 ZZ |
