DSpower

DSpower DS-S003 Servo Motor

$25.00
Version

Delivery and Shipping
  • We automatically select the most cost-effective carrier from China for each destination country
  • Shipping rates are dynamically calculated based on real-time quotes
  • Final rates may vary due to promotional offers or carrier adjustments

Product Information


Application Scenarios

Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots

Technical Specifications

Parameter Value Parameter Value
Product Model DS-S003 Product Model DS-S003M
Operating Voltage 4.8 – 6 V Operating Voltage 4.8 – 6 V DC
No Load Current ≤90 mA No Load Current ≤60 mA at 4.8V
≤70 mA at 6.0V
Stall Current ≤860 mA Stall Current ≤900 mA at 4.8V
≤1 A at 6V
Stall Torque ≥1.2 kgf·cm Rated Torque ≥0.5 kgf·cm at 4.8V
≥0.6 kgf·cm at 6.0V
Rotating Direction CW (Clockwise rotation) at 2000–1000 µs Rotating Direction CCW (1000 → 2000 μs)
Pulse Width Range 500 – 2500 µs Pulse Width Range 1000 ~ 2000 μs
Operating Travel Angle 180° ±10° (500~2500 µs) Operating Travel Angle 90° ± 10°
Return Angle Deviation ≤2° Mechanical Limit Angle 360°
Weight 5.1 ± 0.3 g Return Angle Deviation ≤1°
Output Shaft Specification 28T / Φ3.90 mm Weight 7.8 ± 0.5 g
Cable JR 2.54mm / 3-Pin / Brown, Red, Orange / L = 95 ±5 mm Communication Interface PWM


Wire Length JR / Brown-Red-Orange / 2.54mm, L = 200 ± 5 mm


Output Shaft Specification 28T / Φ3.90 mm

DSpower DS-S003 Servo Motor.pdf
