Xike XK455D Sensor

$190.00
Version
Communication
Range

Delivery and Shipping
  • We automatically select the most cost-effective carrier from China for each destination country
  • Shipping rates are dynamically calculated based on real-time quotes
  • Final rates may vary due to promotional offers or carrier adjustments

Product Information


Application Scenarios

Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots

Technical Specifications

Parameter Value
Model XK455D
Measurement Range ±90°
Measurement Axes X‑Y
Zero Temperature Coefficient -40 to +85 °C, ±0.006/°C
Sensitivity Temperature Coefficient -40 to +85 °C, ≤100 ppm/°C
Frequency Response DC response, 100 Hz
Resolution 0.001°
Accuracy -40 to +85 °C, 0.05°
Long‑term Stability -40 to +85 °C, <0.055°
Power‑on Startup Time 0.15 s
Response Time 0.01 s
Auto Output (Frequency) 5 Hz, 15 Hz, 35 Hz, 50 Hz (settable)
Output Signal (Interface) CAN, CANopen (optional)
Mean Operating Time ≥45,000 hours
Shock Resistance 20000 g, 0.5 ms, 3 times/axis
Vibration Resistance 10 grms, 10~1000 Hz
Insulation Resistance ≥100 MΩ
Ingress Protection IP67 (IP68 customizable)
Cable 1.5 m standard, wear‑resistant, oil‑resistant, wide‑temperature, shielded signal cable 5×0.2 mm²
Weight 150 g (excluding packaging)
