HESAI

HESAI JT128 LiDAR

$1,260.00
Version

Delivery and Shipping
  • We automatically select the most cost-effective carrier from China for each destination country
  • Shipping rates are dynamically calculated based on real-time quotes
  • Final rates may vary due to promotional offers or carrier adjustments

Product Information

Technical Specifications

Parameter Value
   Model   JT128
   Scanning method
  Mechanical rotation
   Number of channels
  128
   Instrumented range   0 to 60 m
   Ranging capability   40 m (at 10% reflectivity, for all channels)
   Horizontal FOV   360°
   Horizontal resolution Approx. 0.4°
   Vertical FOV
95° (-4.4° to 90.5°)
   Vertical resolution
0.74° (average)
   Frame rate
10/20 Hz
Return mode
Single return:   First/Strongest/Last
Dual return:   Last and Strongest (default) / Last and First / First and Strongest
   Wavelength
905 nm
Laser class
Class 1 Eye Safe
Ingress protection
IP6K7
Dimensions
Height: 73.0 mm
Bottom: Φ62.5 mm
Rated voltage range
DC 9 to 32 V
Power consumption
9.5 W
Operating temperature
-20℃ to 65℃
Storage temperature
-40℃ to 85℃
Weight
＜250g
Data transmission
Standard 100Base-TX
Measurements
Distance, azimuth angle, and reflectivity
Point rate
Single Return: 1 152 000 points/sec
Dual Return: 2 304 000 points/sec
Point cloud data rate
82.3 Mbps
Clock source
GNSS/PTP (1588v2, 802.1AS)

HESAI_JT128.stp

JT128_User_Manual.pdf
