SLAMTEC | SKU:
SLAMTEC Aurora S LiDAR
Regular price
$1,100.00
Unit price
SLAMTEC Aurora S LiDAR - Aurora S is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
SLAMTEC Aurora S LiDAR
Regular price
$1,100.00
Unit price
SLAMTEC Aurora S LiDAR - Aurora S is backordered and will ship as soon as it is back in stock.
Product Information
Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
|
Maximum Mapping Area
|
>1,000,000 ㎡
|
|
Relocation
|
Global relocation is supported, with an accuracy ± 5cm
|
|
Map Management
|
Supports incremental mapping, map loading and saving
|
|
Mapping and Localization mode
|
Primarily based on deep learning vSLAM, with optional LiDAR fusion
|
|
Multi-sensor Synchronization Mechanism
|
Hardware time synchronizatio
|
|
Camera Specifications
|
Binocular fisheye, 60mm Baseline, FOV 180°,Global Shutter, RGB
|
|
Camera Frame Rate
|
Typical 15Hz, 10/30Hz can be customized
|
|
Dense Depth Camera Function
|
End-to-end deep learning, robust under strong light and weak texture; >90% detection rate
|
|
AI Object Recognition and Segmentation
|
Supports 18 outdoor scenes and 80 indoor scenes; customizable expansion available
|
|
Maximum Tilt Angle (Optional lidar)
|
No requirement without LiDAR; for better 2D mapping, recommended ≤30°
|
|
2D Map Resolutio (Optional lidar)
|
2cm/5cm/10cm adjustable
|
|
LiDAR Measures Range (Optional lidar)
|
Up to 40m @ 70% reflectivity
|
|
Power Consumption
|
10W (typical, LiDAR not included)
|
|
Operating Temperature
|
-20℃~50℃
|
|
Starting Temperature
|
≥0℃
|
|
Storage Temperature
|
-20℃~60℃
|
