Description
xApplication Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Model | GIM8108-8 |
| Driver Model | SDC104 |
| Nominal Voltage | 48V (24-56V range) |
| Power | 336W |
| Nominal Torque | 7.5 N·m |
| Stall Torque | 22 N·m |
| Nominal Speed after Reduction | 110 RPM |
| Max Speed after Reduction | 320 RPM |
| Nominal Current | 7A |
| Stall Current | 22A |
| Phase Resistance | 0.67 Ω |
| Phase Inductance | 0.45 mH |
| Speed Constant | 6.67 rpm/v |
| Torque Constant | 1 N·m/A |
| Number of Pole Pairs | 21Pairs |
| Gear Ratio | 8:1 |
| Gear Type | Planetary |
| Reducer Gear Material | STEEL |
| Reducer Gear Backlash | 15 arcmin |
| Motor Weight (without Driver) | 378g |
| Motor Weight (with Driver) | 396g |
| Size (without Driver) | Ø92*44mm |
| Size (with Driver) | Ø92*55mm |
| Max Axial Load | 225N |
| Max Radial Load | 900N |
| Noise | <60 dB |
| Communication | CAN & Type-C |
| Second Encoder | YES |
| Protection Grade | IP54 |
| Operating Temperature | -20℃ to +80℃ |
| Encoder Resolution | 16 Bit |
| Separate Encoder Support | No |
| Custom Brake Support | YES |
GIM8108-8_Installation_Diagram.pdf
